Chapter 3: Installation USB Protocol Suite User Manual
66
LeCroy Corporation
Step 6 Click on the Tool Bar.
The system starts to record the USB traffic immediately. After 4 MB of traffic are
recorded, the Analyzer uploads the data and displays the packets in the trace
window.
Step 7 To terminate recording before the snapshot automatically completes,
click on the Tool Bar.
When the recording session finishes, the traffic uploads from the Analyzer to the
hard drive on your PC as a file named data.usb or the name you assigned as the
default filename. While the file is uploading, you should see a brown progress bar
at the bottom of the screen. When the bar disappears, the data has uploaded to
disk.
Step 8 To save a current recording for future reference, select File > Save As on the
Menu Bar.
OR
Click on the Tool Bar to display the standard Save As window.
Give the recording a unique name and save it to the appropriate directory.
