Chapter 9: Reports USB Protocol Suite User Manual
208
LeCroy Corporation
9.11.1 USB3 Link State Timing View Toolbar
The buttons have the following functions:
Vertical zoom in Pointer Mode
Vertical zoom out Hand Panning
Zoom by Selection
Insert Time markers.
After clicking, click in the display to
make a red vertical line. Select and
drag the line to indicate a time
interval between two lines.
Zoom by Horizontal Drag Monitor
Full Screen
Sync by Time.
Synchronize the USB3 Link State
Timing States View and the
Trace View.
Show Downstream port link states. Show Upstream port link states.
