5. Operation of CON Related Controllers
51
No. Operation Screen Remarks
7 Next, touch the target position
of position No. 1.
When the numeric keypad
appears, touch [8], [0] and then
touch [ENT].
To reenter the value, touch
[ESC].
8 When registering a new position
data, the default values set by
user parameters are
automatically entered for the
velocity, acceleration,
deceleration, etc.
In this example, the default
value is 100 mm/s.
9 Next, touch No. "001" of
position No. 1.
10 Touch the value in the Push.
When the numerical keypad
appears, touch [3], [0] and then
touch [ENT].
To reenter the value, touch
[ESC].
11 Touch the value for the
positioning band.
When the numerical keypad
appears, touch [5] and then
touch [ENT].
To reenter the value, touch
[ESC].
12 Touch [Menu1].
