6. Operation of SEP
Related Controllers
145
Operation pattern
Equivalent air cylinder circuits are shown for your reference.
Operation pattern Description
Motorized cylinder connection
method
Air cylinder circuit (reference)
PIO pattern 0
Single solenoid type
(Standard movement
between 2 points)
PIO pattern 0
Double solenoid type
(Standard movement
between 2 points)
The actuator can be moved
between two points using the
same control you normally use
with an air cylinder.
The target position (forward end,
backward end) can be set.
The travel speed and
acceleration/deceleration can be
specified.
Push-motion operation can also
be performed.
PIO pattern 1
Single solenoid type
(Movement between 2
points)
(Change travel speed)
PIO pattern 1
Double solenoid type
(Movement between 2
points)
(Change travel speed)
The actuator can be moved
between two points using the
same control you normally use
with an air cylinder.
The speed can be changed during
movement.
The target position (forward end,
backward end) can be set.
The travel speed and
acceleration/deceleration can be
specified.
Push-motion operation can also
be performed.
(Note) The air cylinder circuits are drawn with signal symbols corresponding to those used by
ASEP/PSEP/DSEP/MSEP controllers.
For details on signal symbols, refer to your "ASEP/PSEP/DSEP Operation Manual","MSEP
controller Operation Manual".
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Forward end
movement signal (ST1)
Backward end
movement signal (ST0)
Motorized cylinder
Dedicated
cable
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Forward end
movement signal (ST1)
Backward end
movement signal (ST0)
Air cylinder
Solenoid
Solenoid
(Air)
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Travel speed switching
signal (SPDC)
Movement signal
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Travel speed switching
signal (SPDC)
Movement signal
Air cylinder
Motorized cylinder
Dedicated
cable
Motorized cylinder
Dedicated
cable
Solenoid
Solenoid
(Air)
(Air)
Air cylinder
Solenoid
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Forward end
movement signal (ST1)
Backward end
movement signal (ST0)
Travel speed switching
signal (SPDC)
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Forward end
movement signal (ST1)
Backward end
movement signal (ST0)
Travel speed switching
signal (SPDC)
Air cylinder
Spring
Solenoid
P (Air)
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Movement signal
(ST0)
Backward end
position detection
signal (LS0)
Forward end position
detection signal (LS1)
Movement signal
(ST0)
Motorized cylinder
Dedicated
cable
Spring
