6. Operation of SEP
Related Controllers
112
6.7 Monitor
The current position, speed, electrical current and system I/O statuses of the controller are displayed.
Touch [Monitor] on the SEP menu screen.
Touch [Menu] to return to the SEP menu screen.
The operation pattern is
indicated.
The I/O statuses of the axis
are indicated.
The display varies depending
on the operation pattern.
The servo status is indicated.
The home return status is indicated.
The axis position is indicated.
The axis speed is indicated.
The electrical current of the axis is
indicated.
