6. Operation of SEP
Related Controllers
108
The menu screen appears.
If multiple units are connected, the
axis selection screen appears.
Select the axis you want
to connect.
[Refer to 6.4, "Changing
Operating Axis."]
[Refer to 6.6, “Menu Selection.”]
[Refer to 6.7, “Monitor.”]
6.3 Initial Screen
Upon connection to the controller, power is supplied to the touch-panel teaching pendant and processing
starts.
When the power is turned on, the IAI logo is displayed for approx. 1 second on the operation display screen
(here in after referred to as "operation screen") of the touch-panel teaching pendant, after which version
information is displayed.
On CON-PDA/PGA pendants,
this screen is displayed when
the enable function parameter
of the controller is set to
“Disable.”
On CON-PTA pendants, this
screen is displayed when the
enable function parameter of
the controller is set to
“Enable.”
* The same items can be set on the
automatic monitor setting screen
accessible from the environment
setting screen of the controller.
