10-86
Chapter 10 Brief guide
This chapter explains the installation steps shown on the DVD for the ABUS wireless alarm package including a smoke detector. After
you have taken the installation steps shown in this guide, your ABUS wireless alarm system is completely operational.
10.1 Hardware installation
10.1.1 ABUS wireless alarm system
• Install the ABUS wireless alarm system in a suitable place in your object.
• Plug the power supply unit into the AC socket of the wireless alarm system. Do not plug in the mains plug yet.
• Connect the telephone line with either a RJ11 telephone plug or two loose cables to the telephone connector of the
system (Line).
• Place the standby batteries provided in the battery holder and then plug this into the wireless alarm system.
• Plug the jumper plug of jumper J10 on the main board on to both pins to charge the batteries.
• Now plug the power supply unit into the mains socket.
The wireless alarm system starts up and soon reports “System is on”. If not, check that the power supply unit is plugged in, that
there is current at the mains socket, and the power supply unit plug is correctly plugged into the wireless alarm system. The fault
LED flashes since the time and date have not yet been entered and the batteries are not fully charged. The batteries should be
fully charged after 12 hours.
• If the system issues an audible alarm when it is switched on, the tamper contact may not be properly pressed. In this case, do
the following:
• Enter the factory default Grand Master PIN on the system keypad:
11 22 33 44
• Press the “Disarm button:
The ABUS wireless alarm system is now ready for programming.
10.1.2 Wireless opening detector
• Install the wireless opening detector at the top centre of the door to be monitored. The magnet is fixed to the movable part of
the door. The magnet and the opening detector must be arranged parallel to each other.
• Insert the battery supplied (check polarity!).
The red LED of the detector lights up.
If not, check that the battery is correctly inserted and measure the battery voltage, which must be above 2.8V.
• Press in the spring of the detector and close the door.
When you open the door, the LED lights up again.
Wait until the LED switches off, then close the door.
The LED must light up again. If not, the magnet and the transmitter are incorrectly positioned or too far apart.
10.1.3 Wireless motion detector
• Install the wireless motion sensor in the corner of a room with a terrace or balcony. The sensor must point into the room and
should not be directed towards large window areas. The red LED of the detector faces up.
IMPORTANT: The infrared detector reacts to heat movement. Therefore, do not point the sensor to fan heaters or other heat
sources. Pets such as cats and dogs can also trigger the detector.
• Insert the battery supplied (check polarity!).
The red LED of the detector lights up.
If not, check that the battery is correctly inserted and measure the battery voltage, which must be above 2.8V.
10.1.4 Wireless smoke detector
• Install the wireless smoke detector in the centre of your bedroom ceiling. Further smoke detectors should be fitted in the living
room and the entrance hall. Smoke always rises first to the highest point of the room.
IMPORTANT: Thick cigarette smoke or water vapour (steam) can trigger the detector.
• Insert the two batteries supplied (check polarity!) and press the test button. Keep the button pressed until the smoke detector
issues a long beep.
If it does not, remove the batteries and wait 30 seconds. Insert the batteries again and repeat the test.
If it fails again, measure the voltage of both batteries. It must be above 2.8V.
• Remove the batteries.
