7-32
7.2.5 11
55
Labels
Under System Label, you name the system and areas 1, 2 and 3, and change default names.
To enter a new name:
Use the buttons of your ABUS wireless alarm system to enter the letters as shown in the table below. When you
press a specific button, you scroll backwards and forwards through the characters. The ABUS wireless alarm
system permits a total of 75 characters for a name (letters, numbers and symbols).
BUTTON PRODUCES THE LETTERS
1 1 A B C D C F G H I Y K L M
2 2 N O P Q R S T U V W X Y Z
3
3 ! ' & ' : – . ? / ( )
4 4 a b c d e f g h i j K l m
5
5 n o p q r s t u v w X y z
6 - 0
Each of these buttons scrolls backwards and forwards between number and space.
Press this button to scroll forwards between the available characters.
Press this button to scroll backwards between the available characters.
Press this button to move the cursor to the left.
Press this button to move the cursor to the right.
Press this button to store a name.
The number of characters permitted varies for each name as follows:
• Zone label: up to 15 characters
• Partition label: up to 12 characters
• Programmable output label: up to 12 characters
• Label of a message to the user: up to 12 characters
• Label for service information: up to 16 characters
• Label for a service name: up to 16 characters
• System label: up to 16 characters
• Label for a user: up to 10 characters
To access the System Label menu:
1. Select the main menu System as described on page 7-24.
2. In the System menu, press 55 to get to the System Label menu option. You see the following on the
display:
3. Select and configure the settings in the System Label menu as follows:
System Label:
Quick-Key Menu option Default Selection
11 55 11 System FUNKALARMANLAGE Any 12
characters
Changes the display for the system name.
