7-53
Activation/Deactivation
If the switch output follows more than one area or zone, you can use different patterns for activating and deactivating the switch output.
ALL or ANY.
All: ALL areas (or zones) programmed for this switch output must be triggered in order to activate the output. On the other hand, all
areas or zones must be inactive in order to deactivate the output. The latter applies only to the outputs Latch N/O and Latch N/C.
The outputs Pulse N/O and Pulse N/C return to inactive automatically after the period defined by you.
Any: Only ONE area (or zone) programmed for this output has to be triggered in order to activate the output. If one of the areas (or
zones) returns to inactive, the output is also deactivated. The latter applies only to the outputs Latch N/O and Latch N/C. The
outputs Pulse N/O and Pulse N/C return to inactive automatically after the period defined by you.
Output label
Define a name for each output, for example lighting control or strobe, describing the function of the output.
7.4.2 33
22
Output A
Under Output A/B, you can define the outputs to be activated with the button function
[4]/ [6] of the ABUS wireless alarm
system.
To access the Ausgang A menu:
1. Select the Output menu as described on page 7-48.
2. In the Output menu, press 22 to access the Output A menu option.
3. Enter the two-digit number of the switch output you want to define as output A, and press
.
7.4.3 33
33
Output B
To access the Output B menu:
1. Select the Output menu as described on page 7-48.
2. In the Output menu, press 33 to access the Output B menu option.
3. Enter the two-digit number of the switch output you want to define as output B, and press
.
