7-39
Parameter
Quick-Key Parameter Default Range
22 22 33 Zone Partition Partitions 1–3
Under Partition, you assign zones to different areas. This is necessary in larger systems to
distinguish, for example, between the commercial area (shop) and the private area (home),
when both are monitored by the ABUS wireless alarm system.
Under Parameters, press
33
to access the Partition menu option. The following
appears on the display:
Enter a two-digit zone number and press . You see the following on the display:
NOTE:
You can assign a zone to one or more areas. The Y under the number shows the area
(1, 2, 3) to which the zone is assigned. A zone that is assigned to more than one area is not
monitored until all assigned areas are activated.
Press [1] to [3] to switch the state of the areas between [Y] YES and [N] NO.
22 22 44 Zone Type
When a detector triggers, it always sends a signal to the alarm system. For
example: A motion sensor reacts to movement, a smoke detector to smoke, etc. So
it is important to tell the system HOW and WHEN it is to react to a signal from a
detector.
Under Zone type, you can program the behaviour of the alarm system when it
receives a signal from a detector. It is absolutely necessary to program this
behaviour since your alarm system will not work without it. The following zone
types are monitored, depending on the state of the alarm system:
1. Disarm: The system reacts to the following zones only: 24-hour, fire, panic and
fault.
2. Arm: The system reacts to all zones.
3. Stay (Internal arm): The system does not react to zones you have programmed
as internal zones. This setting enables you to move within the object when the
perimeter is protected.
There are 22 zone types, whose properties are described in the following:
Under Parameters, press
44
to get to the Zone type menu option. You see the
following on the display:
Enter a two-digit zone number and press .
Select and configure the zone types as follows:
22 22 44 ZZ ZZ
+
00 00
Not used NONE
A zone programmes as not used is not monitored. The alarm system reacts
neither to battery faults, tampering, nor monitoring failure of the detector trained for
this zone. However, a trained detector is not deleted.
