7-52
Output mode
An output mode has to be set for every output. This table gives an overview of the different output modes:
Outputs
Quick-Key Parameter Default Range
11 Pulse N/C 05 seconds 01-90 seconds
The output is closed in non-activated state. Once activated, it remains open until the set
time has elapsed and then resets itself automatically.
1. Press
11
followed by .
2. Enter a pulse duration between 1 and 90 seconds.
3. Press and enter the activation of your choice (ALL or ANY). See the note
on the next page.
4. Press and select a name for the utility output.
22 Latch N/C
The output is closed in non-activated state. Once activated, the output remains open until it
is reset manually.
1. Press
22
followed by .
2. Press and enter the activation of your choice (ALL or ANY). See the note
on the next page.
3. Press and enter the deactivation of your choice (ALL or ANY). See the
note on the next page.
4. Press and select a name for the utility output.
33 Pulse N/O 05 seconds 01-90 seconds
The switch output is open in non-activated state. Once activated, it remains closed until the
set time has elapsed and then resets itself automatically.
1. Press
33
followed by .
2. Enter a pulse duration between 1 and 90 seconds.
3.
Press and enter the activation of your choice (ALL or ANY). See the note
on the next page.
4. Press and select a name for the utility output.
44 Latch N/O
The switch output is open in non-activated state. Once activated, the output remains closed
and may have to be reset manually.
1. Press
44
followed by .
2. Press and enter the activation of your choice (ALL or ANY). See the note
on the next page.
3. Press and enter the deactivation of your choice (ALL or ANY). See the
note on the next page.
4. Press and select a name for the utility output.
