DEMONSTRATION
MILLPWR ®
Operation Manual 4-5
• Now highlight the “Offset” field.
The tool specifications will be filled in automatically
from the information we entered in step 001.
• To cut around the outside of the contour in a clockwise
direction, use a left offset.
• Press the LEFT softkey.
MILLPWR has been factory set with a feed rate of
10 inches per minute, which is fine for this operation.
• Press the USE key.
Notice that the line is immediately displayed on the Program (PGM)
screen. This is called immediate-part-view-graphics.
