To change the hole pattern size, location or number of holes, press the HOLES key
again. Now press the appropriate softkey, enter the new information and then press the
GO key .
This may also be applied to rectangles, circles, lines and arcs. The rectangle and circle
milling functions require you to establish a tool offset. Lines and arcs only require a
tool offset if the tool follows a left or right offset. It’s a good idea to set up a tool
before using either of these function keys. Refer to Program Steps for a complete
description of each function.
Note: The “Tool” setting on MILLPWR ’s status bar (located at the top of the display)
will indicate which tool has been selected. If the “Tool” status bar is blank,
no tool has been selected.
