PROGRAM STEPS

MILLPWR

•

Select a tool offset by pressing the appropriate softkey.

•

Enter the feed rate.

•

If you need to program a 2

corner and/or a tilt angle or would like to program a

finish cut, press the

MORE

softkey. Otherwise, press the

USE

key.

Corner

Enter the X- and Y-axes coordinates for the 2

corner. (The 2

corner must be located diagonally

across from the 1

corner.)

Tilt Angle

Enter the tilt angle.

Finish

Highlight "Cut" in the“Finish” field. Enter the
amount of material to be removed during the finish cut.

Enter the feed rate for the finish cut.

For “Direction,” press either the

softkey for clockwise or the

CCW

softkey for a counter-clockwise direction.

Press the

USE

key.

Note: If the tool size and type listed in the "Tool" field are incorrect, change the tool

settings before running the program (refer to Programming a Tool Step).

Operation Manual

5-16
