PROGRAM STEPS

MILLPWR

Operation Manual

5-53

•

If you need to program a start angle or would like to program a finish cut,
press the

MORE

softkey. Otherwise, press the

USE

key.

Start Angle

You will want to program a start angle if the begin-
ning point of your spiral on the print is tilted—that
is, not positioned at a 0 degree angle (3 o'clock).

Highlight “Start Angle,” then enter the angle of
the spiral’s starting position (measured from the
X-axis).

Finish

Enter the amount of material to be removed during the finish cut.

Enter the feed rate for the finish cut.

Select the direction for the finish cut. Press the

softkey for clockwise or the

CCW

softkey for a counter-clockwise direction.

Press the

USE

key.

Note: If the tool size and type listed in the "Tool" field are incorrect, change the tool

settings before running the program (refer to Programming a Tool Step).
