Using an electronic edge finder:
• From the DRO screen, press the SKEW softkey.
• Touch off on two or more points along any single straight edge of the part. Notice that
the “Points” and “Angle” change as you enter points are entered.
• Press USE to accept all of the points and return to the DRO screen. Press CANCEL to
return to the DRO screen without accepting any points or affecting the previous skew
angle.
The CLEAR ANGLE softkey will reset the number of points and the skew angle to zero.
Using teach position:
• From the DRO screen, press the SKEW softkey.
• Move the table so that a mechanical indicator rests against any straight edge on the
part. Press the
TEACH POSITION softkey to enter the coordinate. Notice that the
“Points” change.
• Now move the table so that the mechanical indicator touches another point on the same
straight edge. Press the
TEACH POSITION softkey. Notice that the “Points” and “Angle”
change.
Repeat this process for any additional points.
• Press USE to accept all of the points and return to the DRO screen. Press CANCEL to
return to the previous screen without affecting the previous skew angle.
The CLEAR ANGLE softkey will reset the number of points and the angle to zero.
