Configuring IP Phone auto-configuration
497
b Click OK.
6
Create the DHCP option for the auto-discovery of VLAN ID
information:
a
In the Predefined Options and Values dialog box, click Add.
The Option Type dialog box opens (see
Option Type dialog box" (page 496)
).
b In the Option Type dialog box, enter the required information
(see
Table 93 "Option Type dialog box field values for VLAN
).
Table 93
Option Type dialog box field values for VLAN Information
Field
Value
Name
VLAN Information
Data type
String
Code
191
Description
Comments (Optional)
c
Click OK.
7
In the Predefined Options and Values dialog box, click OK, to
return to the DCHP Management Console.
--End--
Configuring the Call Server Information and VLAN Information options
For the Auto VLAN Discovery feature, you must configure the options for
both the data (or boot) VLAN and the Phone VLAN. Configure the option
for the data (or boot) VLAN first, then repeat the steps to configure the
option for the Phone VLAN.
To configure the options, perform the following steps.
Step
Action
1
In the DHCP Management Console, expand the required VLAN:
•
first, the data (or boot) VLAN used with the IP Phone
•
when you repeat the steps, the Phone VLAN
2
Right-click Scope Options, and select Configure Options.
The Scope Options dialog box (see
Options dialog box" (page 498)
).
