496 Configuring DHCP to auto-configure IP Phones
Figure 34
The Predefined Options and Values dialog box
4 Click Add.
The Option Type dialog box opens (see Figure 35 "The Option
Type dialog box" (page 496) ).
Figure 35
The Option Type dialog box
5 Create the DHCP option for the call server information.
a In the Option Type dialog box, enter the required information
(see
Table 92 "Option Type dialog box field values for Call
Server Information" (page 496) ).
Table 92
Option Type dialog box field values for Call Server Information
Field Value
Name Call Server Information
Data type String
Code 128 (Call Server configuration)
Description Comments (Optional)
