Figure 127 – Nortel Networks BCM1000 User Manual
Page 267
Chapter 18 Adding or replacing a cooling fan
267
Installation and Maintenance Guide
Figure 127
Fan screws location in BCM1000e, 2.0 models.
Figure 128
Fan screws location in BCM1000e, 2.5 redundancy models.
FAN
Power supply
Fan connector on
hub board
Screws attached to fan
Fan connector
on hub board
Screws attached to fan
Fan connectors
on hub board
