Page 156
156
Chapter 8 Installing media bay modules
P0607659 02
Replacing media bay modules
When media bay modules require replacement, follow the steps in this section.
Figure 56
Process map: Replacing a media bay module
If a media bay module fails, follow this procedure to properly replace the module.
1
Follow the steps in
“Shutting down the system” on page 152
to ensure the system shuts down
correctly.
2
Remove the front bezel from the unit where the module resides.
3
Pull the latch beside the module to be replaced to release the module. Refer to
4
Slide the module out of the bay where it is installed.
5
Record the switch settings from the old module.
Warning:
This section describes replacing a module with the same type of module. If you
want to replace a module with a different type of module, you must treat it as a new
installation. Refer to
Chapter 7, “Setting media bay module DIP switches,” on page 135
and review
to ensure the new module does not overrun any lines
already assigned to other modules.
Module
failure
from the front of
the BCM1000 and
BCM1000e
from both units
from BCM1000 or
BCM1000e
on new module to
match old module
in media bay
to
BCM1000 and
BCM1000e
for
power and status
Check the module
settings in the Unified
Manager
