Page 112: Trunk
112
Chapter 4 Selecting the media bay modules for your system
P0607659 02
Selecting the trunk media bay modules
The number and type of lines coming into your system determine which trunk media bay modules,
and how many modules, you require to support your needs. Trunk lines come from either the
public network (PSTN), or they support connections in a private network.
If you are setting up an entirely new system, a site survey must be done to determine your current
and future needs. We recommend that you do the survey before you order any modules.
To select the trunk media bay modules:
1
Record the number of each type of line you have in
.
If you do not know the number or type of lines you have, contact your service provider.
2
Use the number of lines and the number of lines per module to determine how many modules
you need.
Note:
If you plan to add any lines in the near future, include them in your initial estimates.
Table 10
Determining trunk module requirements
Type of lines
Number of lines
Type of media bay
module
Number of lines
per module
Number of modules
required
T1 digital lines
DTM
24
______ DTM
PRI digital lines (NA)
(required for Companion
wireless)
DTM
23
______ DTM
E1 digital lines
DTM
30
______ DTM
PRI digital lines (EMEA)
DTM
30
______ DTM
Analog lines
CTM
(North American
systems only)
4
______ CTM
Analog lines
CTM8
(North American
systems only)
8
______ CTM
Analog lines
4X16 combination
module
(North American
system only)
4
(also requires a
full DS30 channel
for the DNs)
______ CTM
BRI ISDN lines
BRI
4 ISDN loops
______ BRI
Cordless handsets (DECT)
(selected profiles only)
DECT
4 ISDN loops
(requires a full
DS30 channel)
______ DECT
