Chapter 7 Setting media bay module DIP switches
149
Installation and Maintenance Guide
DECT switch settings
The DECT module supports a maximum of eight DECT radio base station connections. This
module occupies one full DS30 channel, which can support a maximum of 32 cordless handsets
when all eight base stations are deployed.
For detailed instructions about using the DECT module, refer to the Business Communications
Manager 2.5 DECT Installation and Maintenance Guide.
shows the settings for each DS30 channel, and the assigned dialing numbers (DNs).
Table 23
DECT module settings
Select
DS30
channel
Select
offset
Set the switches
Use these
DNs on 2.5
system
Use these
DNs on
updated 2.0
system
**Custom DN range
Offset
DS30 channel
1
2
3
4
5
6
2
0
on
on
on
on
on
on
597-624*
501-532*
3
0
on
on
on
on
on
597-624*
501-532*
off
4
0
on
on
on
on
on
597-624*
501-532*
off
5
0
on
on
on
on
597-624*
501-532*
off
off
6
0
on
on
on
on
on
597-624*
501-532*
off
7***
0
on
on
on
on
597-624*
501-532*
off
off
*If you need more DNs, use DNs in the 565 to 596 range. Ensure no other devices are assigned to these
DNs before you use them. Change the DN type field to ISDN and DECT.
**The extensions listed are based on a three-digit DN with a Start DN of 221. If your system has longer DNs
or a different Start DN, enter the range in the blank column.
***If your system is configured with a 3/5 DS30 channel split, DS30 channel 7 is not available.
