168 Chapter 9 Starting the system
P0607659 02
Setting initial system configurations
After starting the BCM1000, you are ready to set the initial configuration parameters.
The initial configuration defines your Business Communications Manager to the network. It also
gives the system a unique identity and initial parameters. From that point, you can continue with
the specific configurations for your system, which are described in Business Communications
Manager Programming Operations Guide, and the other user guides for each optional application
you choose to add to your system.
Required data parameters
Obtain the following parameter values from an Internet Service Provider (ISP) or corporate
network administrator.
• initial IP address and netmask for each network interface
• primary (and optional secondary) DNS servers
• default next-hop router
• fractional T1 channel numbers (if you are using fractional TI)
• system name
• WAN link protocol
• frame relay DLCI / CIR (if applicable)
• V.90 modem settings (North America only)
Default IP settings
All BCM1000s are shipped with this default address:
• IP: 10.10.10.1
• Subnet: 255.255.255.0
If you can use the default IP address, you can connect the BCM1000 to the LAN, as described in
“Connecting wiring to the LAN card” on page 164 . This allows you to configure to the BCM1000
system from your PC through the Unified Manager.
Note: The initialization chapter of the Programming Operations Guide describes the
information required by the Quick Start Wizard, which includes this information.
Warning: Before using this address on your network, check with your system
administrator. If this address conflicts with the LAN settings, you can cause network
damage if you connect the network without changing the IP address.
