Page 222
222
Chapter 13 Installing Analog Terminal Adapters
P0607659 02
Figure 89
ATA 2 back view
Determining the ATA 2 extension number
You must determine the extension number for every ATA 2 before you can perform administration.
1
Connect a single-line telephone to the ATA 2.
2
Lift the handset.
3
If you do not hear dial tone, press LINK 9 to access an intercom line.
4
Dial the extension number of an Business Communications Manager telephone with a display.
If you hear a busy signal, repeat steps 3 and 4 using a different extension number.
5
When the telephone rings, the display shows: Set
6
The number that appears on the display is the ATA 2 extension number. Record the extension
number.
Note:
LINK appears as RECALL on some telephones. If you are using a telephone
without a LINK or RECALL button, refer to the ATA 2 User Guide for details.
Some phones have a Flash button, which is the equivalent to LINK or RECALL.
Note:
The Automatic Set Relocation feature works with ATA 2.
Mounting keyhole slots
