CHAPTER 2. PIN FUNCTIONS

16

2.3

PROM MODE

The PROM mode is designatable in the

µ

PD75P402 alone.

2.3.1

A0 to A14 (Address) ..... Input

A 15-bit address input pin at PROM write/verify, read. As the PROM built into the

µ

PD75P402 has 2K bytes, it is

addressed by the low-order 11 bits (A0 to A10). A11 to A14 should be fixed to the low level.

2.3.2

O0 to O7 (Data) ..... Input/Output

An 8-bit data input/output pin at PROM write/verify, read.

2.3.3

CE (Chip Enable) ..... Input

A chip enable signal input pin.

2.3.4

OE (Output Enable) ..... Input

An output enable signal input pin.

2.3.5

V

PP

A high voltage application pin at PROM write/verify.

It must be connected to VSS during normal operation.

2.3.6

V

DD

A supply voltage application pin.

2.3.7

V

SS

A GND potential pin.
