143
CHAPTER 7. STANDBY FUNCTION
7.2 STANDBY MODE RESET
The STOP mode is reset only by RESET input. The HALT mode is reset by standby release signal by setting of
an interrupt request flag enabled by the interrupt enable flag and by RESET input.
The standby mode reset operation is shown in Fig. 7-1.
Note When a standby mode (STOP/HALT) was reset by RESET input, the
µ
PD75402A does not insert a wait before
the start of instruction execution. Instruction execution begins simultaneously with resetting of the
standby mode.
(1) STOP mode reset by RESET input
When the RESET input drops from high to low, the oscillator begins to oscillate simultaneously with entry into
the reset state.
When the RESET input level returns from low to high, instruction execution begins even if oscillation is unstable.
Therefore, provide an oscillation stabilization time by making the RESET input low level sufficiently wide.
When the reset state is released, the program branches to the reset start address.
This is different from normal reset operation because the contents of data memory before STOP mode setting
are retained.
(2) HALT mode reset by RESET input
When the RESET input drops from high to low, the HALT mode is reset and the
µ
PD75402A enters the reset state.
When the RESET input level returns from low to high, the program branches to the reset start address and
instruction execution begins.
This is different from the normal reset operation because the contents of data memory before HALT mode setting
are retained.
(3) HALT mode reset by interrupt generation
When an interrupt request flag enabled by interrupt enable flag is set (1), a standby release signal is generated
and the HALT mode is reset. However, the INT0 interrupt request does not generate the standby release signal.
