Main Unit Field Service Malfunction code
4-15
IV
T
roub
lshoo
t
in
g
2.3 Resetting a Malfunction
• To reset a malfunction, turn the Power Switch OFF and then ON again.
2.4 Solutions
2.4.1 0010H: Color PC Drum Motor malfunction
C061
HOLD JOB
ERROR
DUPLEX
Hold job error/No
Duplex unit
• The Duplex Option is not installed, but it is
required for printing the job held in the HDD.
C062
HOLD JOB
ERROR
TRAY 3
Hold job error/No Tray
3
• Tray 3 is not set when the tray 3 is required for
printing of the job hold in HDD.
C063
HOLD JOB
ERROR
TRAY 4
Hold job error/No Tray
4
• Tray 4 is not set when the tray 4 is required for
printing of the job hold in HDD.
C064
HOLD JOB
ERROR
MEMORY
Hold job error/No Mem-
ory
• Expansion memory is not set when the expan-
sion memory is required for printing of the job
hold in HDD.
FFFF
I/F COMM
ERROR
Interface Communica-
tion error
• Correct communication is failed when receiving/
sending the command between PWB-A and
PWB-P.
LCD1
(Service
call ID)
LCD2/LCD3
(Error
description)
Item Detection Timing
Relevant Electrical Parts
Color PC Drum Motor (M2) Mechanical Control Board (PWB-A)
Low Voltage Unit (LV)
Step Action
WIRING DIAGRAM
Control Signal
Location
(Electrical
Component)
1
Check the M2 connector for proper connection
and correct as necessary.
- -
2
Check M2 for proper drive coupling and correct
as necessary.
- -
3
Check the PWB-A connector for proper connec-
tion and correct as necessary.
- -
4
M2 operation check PWB-A PJ14A-8 (LOCK)
PWB-A PJ14A-5 (REM)
11-B
5 Change PWB-A. - -
6 Change LV. -
