Main Unit Field Service Malfunction code
4-13
IV
T
roub
lshoo
t
in
g
004E
POWER
FAN
LV Cooling Fan Motor
malfunction
• The Motor Lock signal remains HIGH for a given
period of consecutive time while the LV Cooling
Fan Motor is being rotated.
0060
FUSER
MOTOR
Fusing Motor malfunc-
tion
• The Fusing Motor does not rotate evenly even
after the lapse of a given period of time while it is
being started.
• The Motor Lock signal remains HIGH for a given
period of consecutive time while the Fusing
Motor is being rotated.
0094
XFER
DETACH 2
2nd image transfer
pressure / retraction
failure
• The Retraction Position Sensor/2nd Image
Transfer is not activated (retracted position)
within a given period of time after the retraction
sequence of the 2nd Transfer Roller has been
started.
• The Retraction Position Sensor/2nd Image
Transfer is not deactivated (pressed position)
within a given period of time after the pressure
sequence of the 2nd Transfer Roller has been
started.
0096
XFER
DETACH 1
1st image transfer
pressure / retraction
failure
• The Retraction Position Sensor/1st Image Trans-
fer is not activated (retracted position) within a
given period of time after the Intermediate Trans-
port Motor has started rotating.
• The Retraction Position Sensor/1st Image Trans-
fer is not deactivated (pressed position) within a
given period of time after the Intermediate Trans-
port Motor has started rotating.
0300
POLYGON
MOTOR
Polygon Motor mal-
function
• The Polygon Motor does not rotate evenly even
after the lapse of a given period of time after it
has been started.
• The Motor Lock signal remains HIGH for a given
period of consecutive time while the Polygon
Motor is being rotated.
0310
LASER
ERROR
Laser malfunction
• The SOS signal is not detected within a given
period of time after the output of the laser has
been started.
0500
FUSER
ERROR
Heating Roller warm-
up failure
• The Heating Roller Thermistor does not detect
the specified temperature and the warm-up cycle
is not completed even after the lapse of a given
period of time after the cycle has been started.
0501
FUSER
ERROR
Fusing Pressure Roller
warm-up failure
• The Fusing Pressure Roller Thermistor does not
detect the specified temperature and the warm-
up cycle is not completed even after the lapse of
a given period of time after the cycle has been
started.
0510
FUSER
ERROR
Abnormally low Heat-
ing Roller temperature
• The temperature detected by the Heating Roller
Thermistor remains lower than the specified
value for a given period of time or longer.
LCD1
(Service
call ID)
LCD2/LCD3
(Error
description)
Item Detection Timing
