6.1.6 Service Call messages
These messages are displayed when error(s) that cannot be handled by the user occur.
The “Error LED
” turns ON while the message is displayed on the Control Panel.
The “Ready LED ” on Control Panel turns OFF while an Operator Call message is dis-
played on the Control Panel.
The Control Panel displays the following description at Service Call.
• A printer icon is displayed with a flashing “Warning icon .”
• A Service Call detected during startup of the printer is displayed as shown in the bottom
of the following picture.
• For the details of each item, see “6.2.3. Service Call messages.”
☞ 3-40
Display Description
LCD 1
A “Warning icon ” is displayed and the Service Call message and a 4-digit-Service Call ID
are displayed on the right (for example, SERVICE CALL C002).
LCD 2
The error description is displayed (for example, RAM ERROR).
LCD 3
LCD 4 No display
State
Error message
Warning icon
Printer icon
Warning icon
State
Error message
4138F3E005DA
SERVICE CALL C002
RAM ERROR
4138F3E019DA
SERVICE CALL C002
RAM ERROR
