Description of the Control Panel (magicolor 5450) Main Unit Field Service
3-38
III
Ad
just
men
t/Set
ting
6.2.2 Operator Call messages
Priority
Message
Description
LCD1 LCD2/LCD3
High 1
COVER OPEN
FRONT
COVER
The Front Door of the machine is open.
SIDE COVER The Right Door of the machine is open.
DUPLEX
COVER
The Duplex Option door is open.
TRAY3 COVER The Right Cover of Tray 3 is open.
TRAY4 COVER The Right Cover of Tray 4 is open.
2
PAPER JAM
☞ For trouble-
shooting
proce-
dures, see
“IV Trouble-
shooting” or
the relevant
Service
Manual of
the option
concerned.
FUSER/EXIT A media jam has occurred at the Fusing section.
SECOND
TRANS A media jam has occurred at the Second Transfer sec-
tion.
VERTICAL
TRANS
A media jam has occurred at the Vertical Conveyance.
DUPLEX1
A media jam has occurred at the Duplex Transport sec-
tion of the Duplex Option.
DUPLEX2
A media jam has occurred at the Duplex Paper Feed
section of the Duplex Option.
TRAY1 A media jam has occurred at Tray 1 (Manual Feed Tray).
TRAY2 A media jam has occurred at Tray 2.
TRAY3 A media jam has occurred at Tray 3.
TRAY4 A media jam has occurred at Tray 4.
3 FUSER MISSING CHECK UNIT The Fusing Unit is not installed.
4 TONER MISSING CHECK UNIT The specified color toner cartridge is not installed.
5
WASTE TONER
FULL REPLACE
BOTTLE
The Waste Toner Bottle is full.
6 TONER EMPTY
REPLACE
Y The specified color toner cartridge has run out.
• If the “TONER EMPTY” menu is set to “CONTINUE,”
a Warning message appears instead of an Operator
Call message.
(Printing doesn't stop even if it is time for the toner
cartridge to be replaced.)
• If the “TONER EMPTY” menu is set to “STOP,” an
Operator Call message is displayed.
(Printing stops when it is time for the toner cartridge
to be replaced.)
REPLACE
M
REPLACE
C
REPLACE
K
7
TRAYX SIZE
ERROR ADD
SSSS *
The media size set in the printer driver does not match
that of the media loaded in the specified tray.
• Load “SSSS” size media in the specified tray.
8
TRAYX TYPE
ERROR ADD
TTTT *
The media size set in the printer driver does not match
that of the media loaded in the specified tray.
• Load “TTTT” type media in the specified tray.
Low 9 ADJUST TRAY1 -
Tray 1 is not installed, but it is selected in the printer
driver.
