5–22
IBM Network Color Printer Operator’s Guide
4. Open the oil recycle bottle and remove the inner seal.
5. Put the oil recycle bottle on a towel on a level surface near the printer.
6. Use the oil removal tool to remove the fuser oil from the oil bottle holder as
follows:
a. Push the top of the oil removal tool all the way down. Insert the pointed
end of the oil removal tool into the oil supply in the oil bottle holder.
Release the pressure on the oil removal tool and allow the oil to flow
into it.
b. Be careful not to spill any oil. Take the oil removal tool out of the oil
bottle holder and insert the pointed end of the tool into the oil recycle
bottle. Push the top of the tool down and force the oil into the recycle
bottle.
c. Repeat step a and step b until you have removed most of the oil from
the oil bottle holder.
