8–6

IBM Network Color Printer Operator’s Guide

Replacing the Air and Ozone Filters

This section guides you through the following procedures:

• Replacing the air filter

• Replacing the ozone filter

You should replace the air and ozone filters every 60 000 prints. Replacement
filters are part of the 60 000-page usage kit.

Use the following procedure to replace the air and ozone filters.

1. Remove the used air filter.

a. Using the ridged grip on the top of the air filter holder [1], pull the holder

out as shown.

b. Position the inside of the holder so that it is facing you.

c. Push up on the filter as illustrated to pop the filter [2] out of the holder [1].
