IBM Network Color Printer Operator’s Guide

5. Hold the cartridge as shown below. Do not hold the cartridge so tightly that

the tabs on the end of the cartridge contact your hand. Pressing the tabs
can partially open the cover of the developing cylinder and damage the
printer. Slowly move each end up and down five or six times to distribute
the toner. (Do not do this with a used or an unsealed toner cartridge.)

6. Remove the 2 protective tapes from the toner cartridge.

7. To remove the sealing tape, put the toner cartridge on a level surface. Hold

the cartridge with one hand and slowly pull the orange tab out with the
other hand. Pull the orange tab straight out to avoid breaking the tape.
