IBM Printing Systems Printers

Infoprint 4100-HD1/HD2 and 4100-PD1/PD2 Printers (4100-HD1/HD2 and
4100-PD1/PD2)

This chapter describes Infoprint 4100-HD1/HD2 and Infoprint 4100-PD1/PD2 printer characteristics. The Infoprint 4100-
HD1/HD2 and 4100-PD1/PD2 printers are channel-attached or LAN-attached, continuous-forms printers that use laser
and electrophotographic technology to print text, images, graphics, and bar codes at up to 762 ipm (impressions per
minute). The Infoprint 4100-HD1/HD2 and 4100-PD1/PD2 printers use the Advanced Function Common Control Unit
(AFCCU) based on RISC technology, which provides as standard the Advanced Function Image and Graphics (AFIG)
feature and the Decompression Performance Enhancement (DPE) feature. The Infoprint 4100-HD1/HD2 has a hard
hot roll which provides high print quality. The Infoprint 4100-PD1/PD2 has a soft hot roll which provides premium print
quality.

The Infoprint 4100-HD1/HD2 and 4100-PD1/PD2 printers also have switchable 480/600 pels-per-inch resolution and
the Print Quality Enhancement (PQE) function, which smooths edges on diagonal lines, protects fine details, improves
the fidelity of images, and allows for adjustment of the boldness of text and the darkness of images.

Figure 45. Infoprint 4100-HD1/HD2 and 4100-PD1/PD2 Printers

Table 139

summarizes the printer characteristics for the Infoprint 4100-HD1/HD2 and 4100-PD1/PD2 printers.

Table 139. Infoprint 4100-HD1/HD2 and 4100-PD1/PD2 Printer Characteristics

Printer Characteristic

Infoprint 4100-HD1/HD2 and 4100-PD1/PD2 Printers

Characteristic Value

Print technology

Laser
