3–6

IBM Network Color Printer Operator’s Guide

8. Press the handle on the underside of the tray upward and slide the tray all

the way into the paper feeder until the tray snaps into place.

The tray is now ready to supply paper.

Loading Paper in the Auxiliary Tray

The auxiliary tray holds approximately 100 sheets of paper at 80 g/m

2

. You

can use letter, legal, A4, or JIS B5-size paper and letter- and A4-size
transparencies. You can close the tray when it is not in use, making the printer
very compact.

Opening the Auxiliary Tray

Use the following procedure to open the auxiliary tray.

1. Pull on the latch to open the auxiliary tray.

2. Pull out the extension tray and then gently press down to lock it.
