Chapter 5. Replacing Supplies
5–21
Removing the Fuser Oil from the Printer
Use the following procedure to remove the fuser oil from the printer.
<2-6> CAUTION:
High temperature; Switch off printer power and allow at least 15 minutes for
parts in this area to cool before handling.
1. Open the fuser access door on the upper right side of the printer.
<2-4> CAUTION:
If spilled, fuser oil causes hazardous surfaces. Prevent anyone from entering
the area until the surface is clean.
2. Lower the fuser oil bottle cover [1]. Lift the oil bottle [2] from the oil bottle
holder and put a towel under the bottle to prevent drops of oil from spilling
on the floor.
Attention:
Do not put the fuser oil bottle or the oil recycle bottle on top of the printer while
recycling oil.
3. Wipe off any excess oil on the bottle and put the bottle upright in a safe
place in the work area.
