2.15 JOG REFERENCE Continued
EXAMPLES: (Continued)
OPERATION BY REMOTE SIGNAL INPUT (RUN & JOG)
JOG2 – 2-WIRE CONFIGURATION
Sn-04 = 0000 (Remote Control)
FREQ. CMD
An-09 JOG
REF.
0
FREQ. CMD
An-09 JOG
REF.
0
* Or FWD
RUN *
JOG1
RUN *
JOG1
2-20
FWD
COMMAND
(EXTERNAL)
JOG2
(FWD OR REV)
FREQ. CMD
An-09 JOG
REF.
0
