25
NV9649
User’s Guide
Checkbox Options
The checkbox options are at the bottom of the panel options section. A check in the box
enables the option. Clearing the checkbox disables the option.
The list of options differs according to whether you have checked the ‘Use Category & Suffix
Pages’ option. These are the panel options when that option is not checked:
Clearing the ‘Use Category & Suffix Pages’ option enables the use of category lists and the panel
options includes an ‘Edit Category Lists’ button. See
Category List on page 27.
See also Clear Configuration Button on page 20.
Checking the ‘Use Category & Suffix Pages’ option enables category pages:
When you have enabled category pages, the panel options include 3 buttons: (1) ‘Edit Src Cate-
gories’, (2) ‘Edit Dst Categories’, and (3) ‘Edit Suffixes’. See
Category and Suffix Pages on page 29.
Release Mode Normal Release This panel can release “locks” and “protects” set by the designated
user (at this panel or any other panel).
Force Release This panel can release locks and protects set by any user.
Default
Destination None After a reset, the panel displays no destination device. (This is
emphatically not recommended.)
‹device› The Panel uses the specified device as the destination after a reset.
(The ‘Default State’ button also returns the panel to this destina-
tion.)
Salvo List [none] Salvo lists appear in the drop-down menu. A salvo list designates
the particular salvos (among potentially many) from which the
operator can choose when the panel is in salvo mode.
Salvo lists are defined, in NV9000-SE Utilities, under the ‘Views’
pane, using the ‘Salvo Lists’ table and the ‘Salvo List Details’ table.
The NV9000 configuration might not have any salvo lists, in which
case ‘None’ is the only entry in the drop-down menu.
