3 The panel ID menu has a numeric “keypad” with which you can enter a new panel ID:
The panel shows the current panel ID on the top left button of the right-hand button matrix.
It shows the panel ID you are entering in the third display (labeled ‘Destination’).
If you make a mistake, press ‘Clear’ to erase your entry and start over.
When you have entered a panel ID correctly, press ‘Save’.
Press ‘Exit’ at any time to leave the panel ID menu. You might have to press ‘Exit’ more than
once to leave the menu entirely.
4 After you enter the panel ID, reconnect the Ethernet cable. The NV9000 system controller
can detect your panel in a few seconds. But it will do so only when the NV9000 has a panel
configuration defined for this panel ID.
(All panel IDs must be unique.)
You can now prepare an NV9649 configuration in NV9000-SE Utilities and upload the configura-
tion to the NV9000. You need the panel ID to create a NV9649 configuration. When you upload
the configuration, the panel ID you entered in NV9000-SE Utilities designates the actual panel to
which the upload will occur. If no actual panel has that ID, the upload cannot occur.
When you restart the NV9000 system controller with the appropriate panel configuration, the
NV9649 you have configured should become active. Its buttons and displays will turn on,
showing meaningful data.
Testing
A panel test function is available when the NV9649 is disconnected from the system controller.
Run the test to determine the health of your NV9649. See
on page 123 for detail.
You can also view the software version numbers under setup mode.
These are points to consider after you install your NV9649 control panel(s):
1 Do the buttons illuminate? When an NV9649 powers up, one or more of its buttons are sup-
posed to turn green or amber. Does it pass the panel test mentioned above?
2 When the NV9649 powers up and it is connected to the system controller, it should initialize
completely. (That takes a few seconds.) The NV9000 system should load whatever configura-
tion exists for that panel and the buttons appropriate for its configuration should light.
If you continue to see “No Server,” “ACQ IP,” or “Locating Network,” you have a problem.
Reboot everything and try again.
The NV9649, by default, acquires its IP address through DHCP on the NV9000’s panel/
router network. You can use the Panel IP Configuration Utility to force the panel to have a
static IP address.
