109
NV9649
User’s Guide
selected, press a ‘Take’ button to execute the salvo. The panel then returns to normal operating
mode.
You can also press ‘Page Up’ and ‘Page Down’ buttons to browse through the salvo list.
Pressing a button other than ‘Take’, ‘Page Up’, or ‘Page Down’ returns to its normal operating
mode.
Source
The button selects a specific source. The source name appears in the ‘Preset’ display.
Selecting a source activates the ‘Take’ button, which you must press to complete the route.
Source Mode
The button places the panel in source mode. Category selections in source mode select source
devices. Category buttons that are not source categories become disabled in source mode.
Categories that include both source and destinations appear in both source mode and destina-
tion mode.
In source mode, a category selection appears at the beginning of the ‘Preset’ display.
Src/Dst Mode
The button toggles between source and destination modes. Category selections in source mode
select source devices. Category selections in destination mode select destination devices.
Source is Master
Means “source is the master” and makes the source device the master. Otherwise, the destina-
tion is the master. This button (and these concepts) apply only to machine control routes.
The button is a toggle: Press it once to make the source the master (it goes high-tally); press it
again to make the destination the master (the button is low-tally).
The ‘Source is Master’ button is also used to initiate “broadcast” machine control routes. See
Broadcast Routes on page 90.
During data level (i.e., machine control) takes, this button makes the source device the master.
Otherwise, the destination is the master.
The button is a toggle that reverses the direction of data routing. For example, if the destination
is the master and the source is the slave, pressing a ‘Source is Master’ button reverses their roles.
Pressing the button again reverses the roles.
The ‘Source is Master’ button is used to initiate “broadcast” control routes. See Broadcast Routes
on page 90.
The panel can be configured so that “source is master” is the default state or so that “destination
is master” is the default. The button still toggles between “source is master” and “destination is
master.”
 Pressing the ‘Source is Master’ button turns off the ‘Broadcast’ button and vice versa.
Take
In normal mode, a take button routes the preset source to the selected destination on selected
level or levels.
