122
Operation
Menu Mode
The panel submenu displays facts about the panel:
The 5 buttons at the left tell you the panel ID, and other useful information about the panel, in
particular, the panel’s IP address. These are useful in a diagnostic situation. This information
helps configurers ensure that they are sending correct configuration file to the correct panel.
The panel acquires its IP address through DHCP on the NV9000’s panel/router network.
If the ‘Panel ID’ button is high-tally, you may change the panel ID. Normally, only your system
administrator would do that. To change the panel ID, press the panel ID button. A panel ID entry
menu appears containing a keypad:
Press the keys of the keypad to enter a number. The number you enter is displayed on the panel
ID button.
Press Cancel to leave the submenu without changing the panel ID.
Press Save to accept your change to the panel ID and leave the submenu.
LCD Control
Press the ‘LCD Control’ button to view and change LCD brightness. When you do, the current
LCD button state appears on the 14 top left buttons:
There are 14 buttons for the 7 button colors. They occur in pairs. The pair shows the high tally
and low tally values for the particular color.
You can change high-tally from high to medium brightness and change low tally to medium or
low brightness, as long as high tally is brighter than low tally. (They cannot both be medium
brightness.)
PANEL ID
PANEL ID
6493
6493
PANEL
PANEL
NAME
NAME
L649
L649
IP ADDR
IP ADDR
192.168.
192.168.
104.84
104.84
SVR NAME
SVR NAME L649
L649
EXIT
EXIT
PANEL ID
PANEL ID
_____649
_____649 0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
CANCEL
CANCEL SAVE
SAVE
LCD HI
LCD HI
GREEN
GREEN
HIGH
HIGH
LCD LO
LCD LO
GREEN
GREEN
LOW
LOW
LCD HI
LCD HI
AMBER
AMBER
HIGH
HIGH
LCD LO
LCD LO
AMBER
AMBER
LOW
LOW
LCD HI
LCD HI
YELLOW
YELLOW
HIGH
HIGH
LCD LO
LCD LO
YELLOW
YELLOW
LOW
LOW
LCD HI
LCD HI
RED
RED
HIGH
HIGH
LCD LO
LCD LO
RED
RED
LOW
LOW
LCD HI
LCD HI
BLUE
BLUE
HIGH
HIGH
LCD LO
LCD LO
BLUE
BLUE
LOW
LOW
LCD HI
LCD HI
PURPLE
PURPLE
HIGH
HIGH
LCD LO
LCD LO
PURPLE
PURPLE
LOW
LOW
LCD HI
LCD HI
GREY
GREY
HIGH
HIGH
LCD LO
LCD LO
GREY
GREY
LOW
LOW
CANCEL
CANCEL SAVE
SAVE
MAKE
MAKE
COLOR
COLOR
BRIGHTER
BRIGHTER
MAKE
MAKE
COLOR
COLOR
DARKER
DARKER
