CNA-8000 Users Guide and Maintenance Manual
707157-001 A-1
Appendix A. Cable Connections Reference
In the event that a cable should happen to be removed from it respective header, below is
a chart referencing the cable and the header/connector it should be mated to.
CABLE FROM TO HEADER
ATX Power Power Supply Motherboard JPW1
+12V 8 Pin Power Supply Motherboard JPW2
SMB Power (I
2
C) Power Supply Motherboard PW4
8.0cm Fan Forward Fan
Housing
Motherboard FAN4
8.0cm Fan Forward Fan
Housing
Motherboard FAN3
8.0cm Fan Forward Fan
Housing
Motherboard FAN2
8.0cm Fan Rear Fan Housing Motherboard FAN1
8.0cm Fan Rear Fan Housing Motherboard FAN5
CPU Fan CPU Fan Motherboard FAN6
DVD Data Front Panel Motherboard SATA0
FDD Data Front Panel Motherboard J27
SATA#0 HDD Bay PCB Motherboard SATA4
SATA#1 HDD Bay PCB Motherboard SATA5
LED Panel 16-Pin
3M
Front Panel Motherboard JF1
Chassis Intrusion Server Frame Motherboard JL1
Power Power Supply HDD Bay PCB
Power Power Supply HDD Bay PCB
Power Power Supply Front Panel Floppy Drive
Power Power Supply Front Panel DVD Power
