System Overview Hardware Description
Page 2 MDE-4465A KE200 Key Encoder/Maintenance Terminal Operation Manual · October 2007
Hardware Description
The KE200 Key Encoder/Maintenance Terminal is a microprocessor controlled unit that
encodes and updates Fleetkeys. It also serves as a maintenance terminal where technicians can
update keys as part of the Fleetkey Maintenance Option.
It can be used in any of the following ways:
• Standalone
• With an ASCII terminal or a Cathode Ray Tube (CRT) monitor
• With a PC using appropriate interface software
The unit is compact and durable, and is equipped with a 20-position tactile feel membrane
keypad and a key receptacle for insertion of Fleetkeys. A Manager's keyswitch is provided
with two key types (Manager and Maintenance) to safeguard the system from unauthorized
access. The system has 32K of battery-backed RAM, which safeguards system data in the
event of a power failure. Two communication ports are provided: an RS-232 logger port,
which is usually used for a printer, and an RS-232/RS-422 port used for communication with
external devices (PC, CRT, and so on). A third port is also available for use with an optional
1200/2400 baud built-in modem.
Power 120 VAC, 60 Hz., 22W. Plugs into any standard 115 VAC
wall outlet. The power line should be free from any surges or
other electrical interference.
Operating Environment 0 to 40° C, 32 to 104° F, with a relative humidity of 20 - 80%,
non-condensing.
Location The KE200 should be located in an office or garage type
environment in an area protected from direct contact with the
weather. It should not be installed over a hazardous location.
