MDE-4465A KE200 Key Encoder/Maintenance Terminal Operation Manual · October 2007 Page 23
Configure ID Fields KE200 Setup - Standalone
Configure ID Fields
Use “CONFIG ID FIELDS” to identify the number of ID fields and the name, size, and format
of each. The system has a set number of predefined field names (VEHICLE, EMPLOYEE,
TRAILER, EQUIPMENT, PATRON, S.S. NO., MISC, DRIVER, ACCOUNT, or
DEPARTMENT). You must choose one of these names. If you have a field that does not
exactly match one of these names, select one that is close or select “MISC”. ID fields used on
CFN systems with the key option must be numeric.
To configure ID fields, proceed as follows:
Number of ID Fields
1 Enter Setup Mode as described previously. The system displays:
SETUP MENU:
LOAD
DATE
2 Press F1 or F2 until the following appears:
SETUP MENU:
CONFIG ID FIELDS
3 Press ENTER. The display prompts:
CONFIG ID MENU:
NO. OF ID FIELDS
4 To identify the number of ID fields, proceed to step 5 . To edit/view ID fields, proceed to step
7 .
5 Press ENTER. The currently loaded value appears on the second line of the display.
NO. OF ID FIELDS
2
6 Type the number of ID fields configured in your FleetKey system and press ENTER. The
display returns to the following:
CONFIG ID MENU:
NO. OF ID FIELDS
