SDM-300A Satellite Modem Revision 6
Remote Control Operation MN/SLM3650.IOM
A–61
Bit 6 = 1 always.
Bit 5 = IF Synthesizer Lock.
Bit 4 = reserved.
Bit 3 = I Channel.
Bit 2 = Q Channel.
Bit 1 = reserved.
Bit 0 = BER threshold.
Character 'f': Demodulator fault status character 3.
Bit 6 = 1 always.
Bit 5 = reserved.
Bit 4 = Configuration.
Bit 3 = reserved.
Bit 2 = reserved.
Bit 1 = reserved.
Bit 0 = reserved.
Character 'g': Interface transmit side faults character 1.
Bit 6 = 1 always.
Bit 5 = reserved.
Bit 4 = reserved.
Bit 3 through Bit 0 = Binary representation (0 to 10) of the
number of interface transmit side stored faults.
Character 'h': Interface transmit side faults character 2.
Bit 6 = 1 always.
Bit 5 = Transmit Data/AIS.
Bit 4 = Transmit Synthesizer PLL Lock.
Bit 3 = Selected Transmit Clock Activity.
Bit 2 = reserved.
Bit 1 = Configuration.
Bit 0 = Drop fault.
Character 'i': Interface transmit side faults character 3.
Bit 6 = 1 always.
Bit 5 = TX Audio Channel 1 Clip.
Bit 4 = TX Audio Channel 2 Clip.
Bit 3 = reserved.
Bit 2 = reserved.
Bit 1 = reserved.
Bit 0 = reserved.
Character 'j': Interface receive side faults character 1.
Bit 6 = 1 always.
