SDM-300A Satellite Modem Revision 6
Front Panel Operation MN/SDM300A.IOM
5–105
FUNCTION SELECT: UTILITY: MODEM TYPE: CARD #3 OPTIONS
CARD #3 OPTIONS
++
Status Only:
REED SOLOMON 02 LIST:
INTELSAT
AUPC
REED SOLOMON 03 LIST:
INTELSAT
AUPC
DUPLEX REED-SOLOMON
INTELSAT
AUPC
(- or +)
(- or +)
(- or +)
(- or +)
(- or +)
(- or +)
FUNCTION SELECT: UTILITY: MODEM TYPE:LOCAL MODEM AUPC
LOCAL MODEM AUPC
OFF
ON or OFF
Configures the modem for the self-monitoring Local Modem AUPC mode and for local TX
power control (self-monitoring) due to severe rain fade.
Notes:
1. The self-monitoring Local Modem AUPC mode is not used when the ASYNC/AUPC
interface option is installed.
2. The Modem must be configured for Duplex operation and the demod locked to the
modulator signal. Refer to Section A.1.4.1.1 for additional information.
FUNCTION SELECT: UTILITY: MODEM TYPE: MODEM SERIAL #
MODEM SERIAL #
012345678
Status Only
