SDM-300A Satellite Modem Revision 6
Remote Control Operation MN/SLM3650.IOM
A–34
DSR_xxx’cr’
RSDE_xxx’cr’
BW_RX1_nnn’cr’ (Note
2)
BW_RX2_nnn’cr’ (Note 2)
BW_RX3_nnn’cr’ (Note 2)
BW_RX4_nnn’cr’ (Note 2)
RXDR_xxxxxx’cr’
ROBR_nnnnn’cr’ (Note
3)
RCCL_n’cr’ (Note 3)
RCSB_n’cr’ (Note 3)
ROCP_xxxx’cr’ (Note 3)
RCT_xxxxx’cr’ (Note 3)
ENSP_nn.n’cr’ (Note 8)
MAXT_n.n’cr’ (Note 8)
RDA_xxx’cr’
RET_xxxxx’cr’ (Note
2)
RRSI_xx’cr’
R310_xxx’cr’
G7LT_xxxxx’cr’’lf’]
Demodulator Spectrum Rotation
Reed-Solomon Decoder
Backward Alarm Enable RX1
Backward Alarm Enable RX2
Backward Alarm Enable RX3
Backward Alarm Enable RX4
RX Driver Type
ASYNC Receive Overhead Baud Rate
ASYNC Receive Channel Character Length
ASYNC Receive Channel Stop Bits
ASYNC Receive Overhead Channel Parity
ASYNC Receive Communications Type
AUPC EBN0 Target Set Point
AUPC Max. Tracking Rate
Receive BPSK Data Ordering
IDR Receive ESC Type
RX Reed-Solomon Interleave Value
RX 8PSK 2/3 IESS-310 Operation
G.703 Unbalanced or Balanced
This command is used by the EF Data M:N protection switch to
collect information that is necessary to configure back-up
modems. Because this command (content and/or order) can be
changed at any time by EF Data, it is advisable that other
commands (‘DCS_’ and ‘ICS_’, or ‘BCS_’) be used for M&C
systems.
Notes:
1. Data is only returned for RX D&I overhead (or Flex Mux D&I mode).is installed.
2. Data is only returned for RX IDR Overhead.
3. Data is only returned for RX ASYNC Overhead.
4. Data is only returned if Flex Mux PCB (Card Slot #1) is installed.
5. Data not returned if Channel #1 is disabled (with Flex Mux PCB installed).
6. Data not returned if Channel #3 is disabled or set for AUPC.
7. Data not returned if Channel #4 is disabled or set for AUPC (with Flex Mux PCB installed).
8. Data is only returned for RX ASYNC Overhead (or Flex Mux AUPC mode).
9. Data is only returned if G.703 Personality PCB is installed.
