SDM-300A Satellite Modem
Revision 6
Remote Control Operation
MN/SLM3650.IOM
A–29
Modulator/
Coder
Config.
Program
Status
Command:
Response:
SMT_xxxxxxx'cr'
ITOT_xxxxx'cr'
MOM_xxxxxxx'cr'
MT_xxxxx'cr'
MET_xxx'cr'
TCEN_1_xxxx'cr'
(Note 6)
TCDR_1_xxxx.x'cr' (Note
7)
TCEN_2_xxx'cr'
(Note 6)
TCEN_3_xxxx'cr'
(Note 6)
TCDR_3_xxxx.x'cr' (Note
8)
TCCP_3_yyy'cr' (Note
8)
TCDP_3_yyy'cr' (Note
8)
TCEN_4_xxxx'cr'
(Note 6)
TCDR_4_xxxx.x'cr' (Note
9)
TCCP_4_yyy'cr' (Note
9)
TCDP_4_yyy'cr' (Note
9)
MF_nnn.nnnnnn'cr'
MR_nnnn_mmmm.mmm'cr'
MPO_snn.n'cr'
LPC_xxx'cr' (Note
10)
MOP_snn.n'cr' (Note
4)
SE_xxx'cr'
DENC_xxx'cr'
ILT_xxx'cr'
ERF_nnnnn.n'cr'
TC_xxxx'cr'
TCP_xxxx'cr'
BBL_xxx'cr'
ILB_xxx'cr'
ILT_xxx'cr'
ICFT_xxxx'cr'
ISP_xxxxxx'cr'
ISP_xxx'cr'
TDF_xxxx'cr'
ISCL_TX1_nnn'cr'
ISCL_TX2_nnn'cr'
TDP_xxxx'cr'
DDF_xxxxxx'cr' (Note
1)
BDCA_dd;cc_dd;cc...'cr' (Note 1)
MRC_xxx'cr'
MSR_xxx'cr'
RSEN_xxx'cr'
BW_TX1_nnn'cr' (Note
2)
BW_TX2_nnn'cr' (Note
2)
BW_TX3_nnn'cr'
(Note 2)
System Modem Type
Interface Transmit Overhead Type
Modem Operation Mode
Modulator Type
Modulator Encoder Type
Flex Mux TX Channel #1 Enable
Flex Mux TX Channel #1 Data Rate
Flex Mux TX Channel #2 Enable
Flex Mux TX Channel #3 Enable
Flex Mux TX Channel #3 Data Rate
Flex Mux TX Channel #3 Clock Phase
Flex Mux TX Channel #3 Data Phase
Flex Mux TX Channel #4 Enable
Flex Mux TX Channel #4 Data Rate
Flex Mux TX Channel #4 Clock Phase
Flex Mux TX Channel #4 Data Phase
Modulator Frequency
Modulator Rate
Modulator Power Offset
AUPC Local Power Enable
Modulator Output Power
Scrambler Enable
Differential Encoder
Interface Loop Timing
External Reference Frequency
Transmit Clock (Source)
Transmit Clock Phase
Baseband Loopback
Interface Loopback
Interface Loop Timing
Interface Coding Format Transmit
Interface Substitution Pattern (TX 2047)
Interface Substitution Pattern (TX 2047)
Transmit Data Fault
Service Channel Level TX1
Service Channel Level TX2
Transmit Data Phase
Drop Data Format
Bulk Drop Channels Assignment
Modulator Reference Clock
Modulator Spectrum Rotation
Reed-Solomon Encoder
Backward Alarm Enable TX1
Backward Alarm Enable TX2
Backward Alarm Enable TX3
