SDM-300A Satellite Modem Revision 6
Front Panel Operation MN/SDM300A.IOM
5–37
FUNCTION SELECT: CONFIGURATION: INTERFACE:INSERT
CHANNEL ASSIGNMENTS (CONDITIONAL)
INSERT CHANNEL
ASSIGNMENTS
IMPORTANT
Conditional: The menu is only available when the optional D&I have
been selected for Modem Type in the Utility menu and the Overhead
card is installed.
Program the satellite channels into one of the following desired terrestrial frame slots:
INSERT SAT CHANNEL TERR For T1, T1_ESF, T1_S, T1_ESF_S
INSERT SAT T-SLOT TERR
For all other formats
Upon entry, satellite channel 1 and the current terrestrial frame slot are displayed. Press [
↑] or
[ ↓] to select the satellite channel to be programmed. Press [ENTER] to choose the satellite
channel to be programmed. Press [ ↑] or [↓] to select the terrestrial frame slot for each available
satellite channel by increasing or decreasing the digit at the flashing cursor. If a time slot is
unused, select NI (Not Inserted). Press [ENTER] to execute the change.
INSERT SAT ---> 1
CHANNEL TERR -> 1
INSERT SAT ---> 1
T-SLOT TERR -> 1
