SDM-300A Satellite Modem Revision 6
Front Panel Operation MN/SDM300A.IOM
5–84
IMPORTANT
Conditional: Only available when the 8PSK option is selected and
Reed-Solomon option is installed and selected.
FUNCTION SELECT: UTILITY: DEMODULATOR: RX IESS-315 MODE
(CONDITIONAL)
RX IESS-315 MODE
OFF
Select: ON or OFF
IMPORTANT
Conditional: Only available when the decoder is TURBO.
FUNCTION SELECT: UTILITY: DEMODULATOR: RX SYMBOL RATE
RX SYMBOL RATE
64.000 Ksps
Status Only. Programmale with 4.800 to 2500 ksps. Provides the symbol rate corresponding to
the data rata, code rate(s), modulation, and overhead (framing) programmed into the
demodulator.
FUNCTION SELECT: UTILITY: DEMODULATOR: RX IESS-315 MODE
(CONDITIONAL)
RX IESS-315 MODE
OFF
Select: ON or OFF
IMPORTANT
Conditional: Only available when encoder is TURBO.
